Auger Torque Auger Extensions – S4, S5, S6 and PA, Fixed or Telescopic
Price and lead time confirmed with your quote
Price on request
Request a quote
Prices depend on your machine and the options you need, so every attachment is quoted individually.
Auger extensions fit between your earth drill and the auger, so you can drill deeper than the auger's own length allows. Auger Torque makes fixed extensions for its S4, S5, S6 and PA augers, and telescopic extensions for S5, S6 and PA.
Telescopic extensions adjust to three heights, which Auger Torque says cuts the time spent swapping extensions on deep holes. They aren't suitable for 150mm to 250mm S5 or S6 augers, and each has a torque limit, shown below.
Specifications
| Series | Fits earth drills | Fixed lengths | Telescopic lengths | Telescopic torque limit |
|---|---|---|---|---|
| S4 (65mm round) | X1500 to 4500 MAX, ML1500 to ML2500, 3000TC | 500mm or 1m (others on request) | Not available | – |
| S5 (75mm square) | 5500 MAX to 8000 MAX, 5500TC, 7000TC | 1m, 1.5m or 2m | 1.5m or 2m | 16,000Nm |
| S6 (75mm square) | 10000 to 25000 MAX | 1.5m, 2m, 2.5m or 3m | 1.5m or 2m | 16,000Nm |
| PA (110mm square) | 35,000 MAX to 65,000 MAX | 2m or 3m | 2m or 3m | 42,000Nm |
Key Features
- Drill deeper without buying a longer auger
- Fixed extensions for S4, S5, S6 and PA augers
- Telescopic extensions adjust to three heights
- Each series matches its auger's hub
Before You Order
Tell us your earth drill, the auger series and diameter, and the depth you need to reach, and we'll quote the extension to suit. A longer auger string is heavier and holds more spoil, so stay within your machine's lifting limits when you lift it out of the hole.
Our guide on what size auger you need covers matching augers to your drive. Then request a quote.
Related Attachments
Need the augers too? See the S4, S5, S6 and PA augers. Spare teeth are on our auger teeth and pilots page. Browse all our excavator augers.
Request a quote
Tell us your machine's make, model and weight, and its auxiliary oil flow if you know it, and we'll come back with a price, lead time and delivery cost.
